R405 Drilling Rig | Micropiles - Casing - Geothermal - Construction
The Rock Drill R405 Drilling Rig is a low headroom micro piling drilling unit ideally suited for restricted access drilling sites and underground geothermal applications. Compatible with mud or air drilling setups. Standard features include breakout clamps, separate remote power unit, width adjustable crawler tracks, adjustable stabilizer legs and a high torque JT200-Series drill head.
- Height7′ 3″ (2,172 mm)
- Mast Stroke4′ 7″ (1,397 mm)
- Pullback22,000 lbs (10,000 kg)
- Rig WeightApprox. 5,200 lbs (2,359 kg)* not including hydraulic hoses.
- ClampsMultiple options available
WATCH THE VIDEO
05
Configurable Torque/RPM options
02
Speed Rotary Head
01
Main Shaft Construction
The Rock Drill R405 Drill Rig is a low-headroom, restricted access drilling unit with a remote power unit. The remote power unit can be placed up to 200 ft away from the rig with umbilical hoses.
With the high torque JT200 Series Drill Head the Rock Drill R405 is a powerful and compact drilling unit for micro piling and limited access drilling applications.
INNOVATIVE SIMPLICITY
With their own practical drilling experience the Mincon Rock Drill engineers used innovative simplicity to design a series of drilling units that were easy to maintain and service. This engineering methodology designed a series of machines that are built to last:
Engineered simplicity also means components are stronger and more durable.
Maintenance requirements are reduced with fewer wearable items and moving parts.
Off-the-shelf parts and spares can be utilized from local suppliers, Lowering maintenance and operating costs.
The Rock Drill R405 is a powerful, restricted access drill rig for low head room applications.
SPECIFICATIONS
POWER & HYDRAULICS :
| Description | Imperial | Metric |
|---|---|---|
| System Pressure | 3,000 psi | 206 bar |
| Max Flow | 33 gpm | 124 lpm |
| Max Pullback | 22,000 lbs | 10,000 kg |
| Max Pushdown | 16,000 lbs | 7,257 kg |
| Engine Power | 83hp | 61 kW |
| Fuel Tank | 31 gallons | 117 ltr |
| Hydraulic Tank | 55 gallons | 189 ltr |
| Cooling System | Air Cooled |
| Description | Imperial | Metric |
|---|---|---|
| Max Torque | 10,400 ft-lbs with JT205 | 14,000 Nm |
| Max Speed | 205 rpm with JT222-M | |
| Through Bore | 2-3/8” | 60 mm |
| Speeds | 2-Speed Variable |
DIMENSIONS & WEIGHT :
| Description | Imperial | Metric |
|---|---|---|
| Height (Drilling Position) | 7’ 3” | 2,172 mm |
| Height (Transport Position) | 59” | 1,499 mm |
| Length (Drilling Position) | 83” | 2,108 mm |
| Mast Stroke | 4’ 7” | 1,397 mm |
| Width | 34”-52" | 863-1,320 mm |
| Rig Weight Approx. | 5,200 lbs* | 2,359 kg* |
| System Pressure |
|---|
| 3,000 psi (206 bar) |
| Max Flow |
|---|
| 33 gpm (124 lpm) |
| Max Pullback |
|---|
| 22,000 lbs (10,000 kg) |
| Max Pushdown |
|---|
| 16,000 lbs (7,257 kg) |
| Engine Power |
|---|
| 83hp (61 kW) |
| Fuel Tank |
|---|
| 31 gallons ( 117 ltr) |
| Hydraulic Tank |
|---|
| 55 gallons (189 ltr) |
| Cooling System |
|---|
| Air Cooled |
| Max Torque |
|---|
| 10,400 ft-lbs with JT205 (14,000 Nm) |
| Max Speed |
|---|
| 205 rpm with JT222-M |
| Through Bore |
|---|
| 2-3/8” (60 mm) |
| Speeds |
|---|
| 2-Speed Variable |
| Height (Drilling Position) |
|---|
| 7’ 3” (1,499 mm) |
| Height (Transport Position) |
|---|
| 59” (75-90 lpm) |
| Length (Drilling Position) |
|---|
| 83” 2,108 mm |
| Mast Stroke |
|---|
| 4’ 7” 1,397 mm |
| Width |
|---|
| 34”-52″ 863-1,320 mm |
| Rig Weight Approx. |
|---|
| 5,200 lbs* (2,359 kg*) |
