R612 Drilling Rig | Water Well - Geothermal - Micropiles - Construction
The Rock Drill R612 is a powerful and versatile drilling rig with setups for micropiles, geothermal, geotechnical and water well drilling applications. High torque and high speed drill head options are available. The Rock Drill R612 is a capable geothermal drilling rig for residential and commercial geothermal projects.
The Rock Drill R612 is capable of running augers, sampling tooling, DTH hammers, top hammers, mud drilling equipment and more.
- Height18′ 3″ (5,493 mm)
- Mast Stroke11′ 10″ ( 3,600 mm)
- Pullback22,000 lbs (10,000 kg)
- Weight10,955 lbs (4,970 kg)* not including hydraulic hoses.
- Clamp SystemMultiple options available
WATCH THE VIDEO
Only 5ft Wide
Speed Rotary Head
10ft Drill Rod Rack
The Rock Drill R612 Drilling Rig a powerful and compact water well and geothermal drilling rig. With low maintenance requirements the Rock Drill R612 helps to lower cost per foot of drilling in even the toughest drilling conditions.
The JT200 Series Drill Head and modular Clamp Systems offer customizations for multiple drilling tooling packages, applications and drill requirements.
DRILL TOOLING PACKAGES
A modular design philosophy means that our Rock Drill rigs and mast attachments can be quickly customized to your application and tooling setup. Need to breakout casings? Choose our Double Breakout Clamps system that can easily be added to your equipment specification.
- Modular options give you control over your drilling unit setup
- Easily retrofit our modular options on to existing drilling rigs
- Modular design makes customizations easier and lower cost
- Adds to easy maintenance and parts replacement
POWER & HYDRAULICS :
|System Pressure||3,000 psi||206 bar|
|Max Flow||47 gpm||180 lpm|
|Max Pullback||22,000 lbs||10,000 kg|
|Max Pushdown||16,000 lbs||7,257 kg|
|Engine Power||90 hp||70 kW|
|Fuel Tank||31 gallons||117 ltr|
|Hydraulic Tank||65 gallons||248 ltr|
|Cooling System||Liquid Cooled|
ROTARY HEADS : (D4 Drill Head)
|Max Torque||10,400 ft.lbs with JT205||14,000 Nm|
|Max Speed||205 rpm with JT222-M|
|Through Bore||2-3/8”||60 mm|
|Height (Drilling Position)||18’ 3”||5,493 mm|
|Height (Transport Position)||7’ 2”||2,184 mm|
|Length (Drilling Position with Lubricator)||13' 2'||4,017 mm|
|Mast Stroke||11’ 10”||3,600 mm|
|Weight||10,955 lbs||4,970 kg|
|Track Width||60”||1,524 mm|
|Track Length||90”||2,286 mm|
|3,000 psi (206 bar)|
|47 gpm (180 lpm)|
|22,000 lbs (10,000 kg)|
|16,000 lbs (7,257 kg)|
|90 hp (70 kW)|
|31 gallons (117 ltr)|
|65 gallons (248 ltr)|
